Technisches Datenblatt
250 x 60 mm drive wheel, antistatic (ESD), bore: 25 mm, with conductive PU tread, aluminum rim
Artikelnummer: 6901-ATR-AS/250/60/60/25
Beschreibung
Antistatic Drive Wheel 250×60 mm, bore 25 mm, hub length 60 mm, with conductive polyurethane tread and aluminum rim.The conductive PU tread guarantees a dissipation resistance of R ≤ 50 MΩ and reliably prevents electrostatic charges. Suitable for use in ESD areas, cleanrooms, electronics manufacturing, EX zones, and cleanroom environments where hazardous static discharges must be prevented. Dynamic load capacity: ...
Technische Daten
| Rad-Ø | 250 mm |
|---|---|
| Radbreite | 60 mm |
| Achsloch-Ø | 25 mm |
| Achsloch-Passung | H7 |
| Nabenlänge | 60 mm |
| Nabennutbreite (N1) | 3.3 mm |
| Nabennuthöhe (N2) | 8mm |
| Passung Nabennut | JS9 |
| Tragfähigkeit | 1400 kg |
| Temperaturbereich | -20° / +80° C. |
| Leitfähigkeit | Antistatic |
| Ableitwiderstand | R ≤ 50 MΩ |
| Kontaktverfärbungsfrei | Ja |
| Spurlos | Ja |
| Hitzebeständig | Nein |
| Autoklaventauglich | Nein |
| Rollwiderstand | 4 |
| Dämpfung | 2 |
| Korrosionsbeständigkeit | 3 |
| Verschleißbeständigkeit | 4 |
| Material | Polyurethane (PU), Aluminium |
| Härte der Lauffläche | 92° Shore A. |
| Farbe | black |
| Gewicht | 1000 g |
Hersteller
rollen-direkt - Heidestr. 38 a - 59174 Kamen - Tel. 02307 - 9644987
Sicherheitshinweis
Product Safety – Drive Wheels Intended Use This drive wheel is intended for use in industrial machinery, conveyor systems, automated guided vehicles (AGVs), industrial trucks, or similar technical systems. The product may only be used in accordance with its technical specifications. Assembly Assembly may only be...
