Drive Wheel 230x85/50 mm | Polyurethane | Hole Pattern 4×14 mm |

Drive Wheel 230x85/50 mm | Polyurethane | Hole Pattern 4×14 mm |
  • Drive Wheel 230x85/50 mm | Polyurethane | Hole Pattern 4×14 mm |
183,27 €
IVA incluído
149,00 €
sem IVA
Production manufacturing
approx. 7–12 days
The product is manufactured after the order has been placed.
Customers rate us 4.9/5 based on 10 reviews.
Request a quote

Technische Daten

Wheel diameter (D)
230mm
Wheel width (B)
85.0mm
Load capacity
1000kg
Axle hole (d1)
50.0mm
Schraubloch-Ø
14mm
Lochbild
4x80mm
Kontaktverfärbungsfrei
Ja
Spurlos
Ja
Härte der Lauffläche
92° Shore A.

Drive Wheel 230x85 mm, Polyurethane

Technical Data

  • Diameter: 230 mm
  • Wheel Width: 85 mm
  • Bore / Hub: 50 mm
  • Material: Polyurethane
  • Bolt Hole Pattern: 4×14 mm
  • Pitch Circle Diameter: 80 mm
  • Bolt Hole Diameter: 14 mm
  • Area of Use: Pallet Truck / Forklift
  • Item Number: AR-230-85-50-POL

Matching OEM and Comparison Numbers

  • Jungheinrich: 71340040
  • Linde: 0633916
  • Steinbock: 0633916, 0630574, 0630575
  • Other: 13441141, 40387935

Note: Before ordering, please check the dimensions, bore, bolt hole pattern, and the OEM/comparison numbers on your existing wheel.

All mentioned brand and manufacturer names are for compatibility identification purposes only. This is not an original part from the respective manufacturers.
