Guide roller | 100×25 mm | Vulkollan® | bore Ø15 mm | 210 kg | ball bearing

guide roller 100×25 mm Vulkollan® Kugellager 210 kg bore Ø15 mm

94,40 €

incl. VAT

75,22 €

excl. VAT

Production or assembly

approx. 3–7 days

The item will be assembled after receipt of your order.

Free shipping from €99 net
Delivery in 1–3 working days
Personal advice: +49 2307 9644987
Specialist retailer online since 2004

Technical data

Wheel diameter (D)

100 mm

Wheel width (B)

25 mm

Load capacity

210 kg

Hub length (C)

20 mm

Bore (d1)

15 mm

Non-marking

Yes

Non-marking

Yes

Guide Roller 100x25 mm – Vulkollan® 92° Shore A / Steel Body

The 100x25 mm guide roller (with steel body and Vulkollan® tread (92° Shore A), ZZ precision ball bearing) is designed for precise guiding tasks in conveyor technology, special machinery, and intralogistics. Load capacity 210 kg, bore Ø15 mm, hub length 20 mm – ready for direct installation. Typical applications include guide rollers in conveyor technology and mechanical engineering.

Technical Features

Outer diameter: 100 mm
Wheel width: 25 mm
Hub length: 20 mm
Bore: Ø15 mm
Load capacity: 210 kg
Material: Vulkollan® 92° Shore A / Steel body
Bearing: Ball bearing centered, secured with circlip

Areas of Application

Guide rollers in conveyor and transport systems
Special machines, fixtures, and linear guides
Warehouse and intralogistics systems
Gravity conveyor lines and assembly systems

Selection Notes

Please check axle diameter and axial installation situation before ordering. The circlip is included in the scope of delivery.
