Guide roller | 80×22 mm | Steel S355 | Bore Ø20 mm | 180 kg | Ball bearing

guide roller 80×22 mm steel S355 Kugellager 180 kg bore Ø20 mm
  • guide roller 80×22 mm steel S355 Kugellager 180 kg bore Ø20 mm
35,14 €
IVA incluído
28,57 €
sem IVA
Production manufacturing
approx. 7–12 days
The product is manufactured after the order has been placed.
Version
Customers rate us 4.9/5 based on 10 reviews.
Request a quote

Technische Daten

Wheel diameter (D)
80mm
Wheel width (B)
22.0mm
Load capacity
180kg
Hub length (C)
14.0mm
Axle hole (d1)
20.0mm
Spurlos
Ja

Guide Roller 80×22 mm – S355 Bright Steel

The 80×22 mm guide roller (made of S355 bright steel, with central ball bearing secured by a circlip) is designed for precise guiding tasks in conveyor technology, special machinery, and intralogistics. Load capacity 180 kg, bore Ø20 mm, hub length 14 mm – ready for immediate installation. Typical applications include guide rollers in conveyor technology and mechanical engineering.

Technical Features

  • Outer diameter: 80 mm
  • Wheel width: 22 mm
  • Hub length: 14 mm
  • Bore: Ø20 mm
  • Load capacity: 180 kg
  • Material: S355 bright steel
  • Bearing: Central ball bearing, secured with circlip

Areas of Application

  • Guide rollers in conveying and transport systems
  • Special machinery, fixtures, and linear guides
  • Warehouse and intralogistics systems
  • Gravity conveyor lines and assembly systems

Selection Notes

Please check the axle diameter and axial mounting situation before ordering. The circlip is included in the scope of delivery.
