Guide roller | 100×22 mm | Stainless steel 1.4301 | Bore Ø20 mm | 240 kg | Ball bearing

Guide roller 100×22 mm – Stainless steel 1.4301

The 100×22 mm guide roller (made of stainless steel 1.4301, with a central ball bearing secured by a circlip) is designed for precise guiding tasks in conveying technology, special machinery, and intralogistics. Load capacity 240 kg, bore Ø20 mm, hub length 14 mm – ready for direct installation. Typical applications include guide rollers in conveying technology and mechanical engineering.

Technical Features

• Outer diameter: 100 mm
• Wheel width: 22 mm
• Hub length: 14 mm
• Bore: Ø20 mm
• Load capacity: 240 kg
• Material: Stainless steel 1.4301
• Bearing: Central ball bearing, secured with circlip

Areas of Application

• Guide rollers in conveying and transport systems
• Special machinery, fixtures, and linear guides
• Warehouse and intralogistics systems
• Gravity conveyor lines and assembly systems

Selection Notes

Please check the axle diameter and axial installation situation before ordering. The circlip is included in the scope of delivery.
