U-groove roller polyamide 6G 100×40 mm for 30 mm pipe (R=15 mm), bore 12 mm with keyway

U-groove roller polyamide 6G with keyway Ø250 mm
77,81 €
incl. VAT
62,00 €
excl. VAT
Made to order
approx. 7–12 days
The item will be produced after receipt of your order.
Customers rate us 4.6/5 based on 18 reviews.
  • Free shipping from €99 net
  • Delivery in 1–3 working days
  • Personal advice: +49 2307 9644987
  • Specialist retailer online since 2004

Technical data

Wheel diameter (D)
100 mm
Wheel width (B)
40 mm
Groove radius (R)
15
Tube diameter
30 mm
Load capacity
400 kg
Material
Polyamide 6G
Temperature
-30 °C to +80 °C
Tread hardness
90 Shore D
Axle bore fit
H7
Hub keyway fit
JS9
Hub groove height (N2)
1.8
Hub groove width (N1)
4
Weight
0.248 kg

U-groove roller made of polyamide 6G with keyway and circumferential U-groove tread contour for secure guidance on a tube with Ø 30 mm. The bore has a hub groove according to DIN 6885 and can therefore be connected to a shaft in a torsion-proof manner – for driven rollers and drive functions. Polyamide 6G is a high-strength, abrasion-resistant technical plastic with low weight, quiet running and gentle on the mating surface. Manufactured to order.

Technical data

  • Outside diameter: 100 mm
  • Total width: 40 mm
  • Tread width: 40 mm
  • Bore diameter: 12 mm, fit H7
  • Hub groove: 4 mm wide, 1.8 mm deep, fit JS9 – keyway according to DIN 6885
  • Suitable for tube Ø: 30 mm (R=15 mm)
  • Load capacity: 400 kg
  • Material of wheel and tread: Polyamide 6G (PA6G), natural colour
  • Temperature range: -30 °C to +80 °C

Keyway instead of ball bearing

This version does not run on ball bearings, but sits torsion-proof on the shaft. The hub groove according to DIN 6885 accepts a key and thus transmits the torque between shaft and roller. Typical for driven conveyor tracks, deflection pulleys on shafts and all applications where the roller should rotate with the shaft rather than run freely. If the roller is needed as a free-running version instead, the version with ball bearings is the right choice.

Properties of polyamide 6G

  • High strength with low weight
  • Very good abrasion resistance and wear resistance
  • Quiet running compared with steel on steel
  • Gentle on the steel mating surface (tube)
  • Resistant to oils, greases and many chemicals
  • Electrically insulating

Applications

U-groove rollers made of polyamide 6G with keyway are used where the roller is driven via a shaft or must sit torsion-proof: conveyor lines in mechanical engineering, special-purpose machines, overhead conveyor systems and noise-sensitive applications.

Manufactured to order. For applications with direct food contact, please request a separate food-grade version.
