Guide roller | 45×20 mm | bore Ø12 mm | 140 kg | Polyamide 6G | ball bearing

Guide roller 45×20 mm made of polyamide 6G

The guide roller 45×20 mm made of cast polyamide 6G (PA6G) is designed for precise guiding tasks in conveyor technology, special-purpose machinery and intralogistics. With a load capacity of 140 kg, a bore of Ø12 mm and a hub length of 8 mm, it is ready to install straight away and requires little maintenance. The built-in deep groove ball bearing is axially secured with a circlip – optionally as a standard or stainless steel version (Nirosta), for permanently play-free, smooth running even under continuous load. Typical areas of application are guide rollers in conveyor technology and mechanical engineering.

Design & material

The wheel body is precisely turned from cast polyamide 6 (PA6G). PA6G is characterised by high wear resistance, good chemical resistance, low noise generation and electrical non-conductivity. Compared with steel rollers, the weight is significantly reduced – with equivalent load-bearing capacity. The ball bearing is axially secured by a circlip, which enables straightforward mounting on an axle or bolt without any additional fixing elements.

Technical features

• Outside diameter: 45 mm
• Wheel width: 20 mm
• Hub length: 8 mm
• Bore: Ø12 mm
• Load capacity: 140 kg
• Bearing: deep groove ball bearing, axially secured with circlip – optionally stainless steel (Nirosta, non-rusting)
• Material: polyamide 6G (PA6G), cast and turned
• Electrically non-conductive, corrosion-free
• Suitable for food contact in accordance with standard PA norms

Areas of use

• Guide rollers in conveyor and transport systems
• Special-purpose machinery, jigs and linear guides
• Warehousing and intralogistics systems
• Gravity conveyor lines and assembly systems
• Wherever a light, quiet and corrosion-free running performance is required

Notes on selection

Please check axle diameter and axial installation situation before ordering. The circlip is included in the scope of delivery. Via the “Bearing” selection you can choose the roller either with a standard ball bearing or with a stainless steel ball bearing (Nirosta). For special dimensions or other materials (e.g. PA6G + MoS₂), please contact us.
