Guide roller | 125×30 mm | Steel S355 | bore Ø25 mm | 320 kg | ball bearing

Guide roller 125×30 mm steel S355 ball bearing 320 kg bore Ø25 mm
86,53 €
incl. VAT
68,95 €
excl. VAT
Made to order
approx. 7–12 days
The item will be produced after receipt of your order.
Variantdefault
Customers rate us 4.6/5 based on 18 reviews.
  • Free shipping from €99 net
  • Delivery in 1–3 working days
  • Personal advice: +49 2307 9644987
  • Specialist retailer online since 2004

Technical data

Wheel diameter (D)
125 mm
Wheel width (B)
30 mm
Load capacity
320 kg
Hub length (C)
12 mm
Bore (d1)
25 mm
Non-marking
Yes

Guide roller 125×30 mm – steel S355 bright

The guide roller 125×30 mm (made of steel S355 bright, ball bearing centrally positioned, secured with retaining ring) is designed for precise guiding tasks in conveyor technology, special-purpose machinery and intralogistics. Load capacity 320 kg, bore Ø25 mm, hub length 12 mm – ready for direct installation. Typical areas of use are guide rollers in conveyor technology and mechanical engineering.

Technical features

  • Outside diameter: 125 mm
  • Wheel width: 30 mm
  • Hub length: 12 mm
  • Bore: Ø25 mm
  • Load capacity: 320 kg
  • Material: steel S355 bright
  • Bearing: ball bearing centrally positioned, secured with retaining ring

Areas of application

  • Guide rollers in conveyor and transport systems
  • Special-purpose machinery, fixtures and linear guides
  • Warehouse and intralogistics systems
  • Gravity conveyor lines and assembly systems

Selection notes

Please check axle diameter and axial installation situation before ordering. The retaining ring is included in the scope of delivery.
