Guide roller | 50×15 mm | Steel S355 | bore Ø10 mm | 140 kg | ball bearing

Guide roller 50×15 mm steel S355 ball bearing 140 kg bore Ø10 mm
39,81 €
incl. VAT
31,72 €
excl. VAT
Custom-made product
Please ask about the delivery time in advance
Custom-made product – please ask about the delivery time in advance.
Variantdefault
Request product
Customers rate us 4.6/5 based on 18 reviews.
  • Free shipping from €99 net
  • Delivery in 1–3 working days
  • Personal advice: +49 2307 9644987
  • Specialist retailer online since 2004

Technical data

Wheel diameter (D)
50 mm
Wheel width (B)
15 mm
Load capacity
140 kg
Hub length (C)
8 mm
Bore (d1)
10 mm
Non-marking
Yes
Temperature
-20 °C to +80 °C
Tread hardness
200-230 HB

Guide roller 50×15 mm – steel S355 bright

The guide roller 50×15 mm (made of steel S355 bright, ball bearing centrally positioned, secured with retaining ring) is designed for precise guiding tasks in conveyor technology, special-purpose machinery and intralogistics. Load capacity 140 kg, bore Ø10 mm, hub length 8 mm – ready for direct installation. Typical areas of use are guide rollers in conveyor technology and mechanical engineering.

Technical features

  • Outside diameter: 50 mm
  • Wheel width: 15 mm
  • Hub length: 8 mm
  • Bore: Ø10 mm
  • Load capacity: 140 kg
  • Material: steel S355 bright
  • Bearing: ball bearing centrally positioned, secured with retaining ring

Areas of application

  • Guide rollers in conveyor and transport systems
  • Special-purpose machinery, fixtures and linear guides
  • Warehouse and intralogistics systems
  • Gravity conveyor lines and assembly systems

Selection notes

Please check axle diameter and axial installation situation before ordering. The retaining ring is included in the scope of delivery.
